ASUS PRIME B760M-K DDR5 12TH AND 13TH GEN MICRO-ATX MOTHERBOARD PRICE IN BD
The ASUS PRIME B760M-K DDR5 Micro-ATX Motherboard now available at TechLand BD. It is a high-performance motherboard designed for 13th Gen Intel® Core™, 12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors. It features an Intel® B760 Chipset and supports DDR5 memory modules with speeds up to 8000 MT/s. The motherboard has 2 DIMM slots, supporting up to 96 GB of system memory. The motherboard comes with an integrated graphics processor, supporting a maximum resolution of 4096x2160@60 Hz on HDMI. It also supports VGA output. For audio, it uses a Realtek 7.1 Surround Sound High Definition Audio CODEC and supports jack-detection, multi-streaming, and front panel jack-retasking. The motherboard has multiple expansion slots, including a PCIe 4.0 x16 slot and two PCIe 4.0 x1 slots. It also has multiple storage interfaces, including two M.2 slots and four SATA 6Gb/s ports. The motherboard supports USB 3.2 Gen 1 and USB 2.0 ports, both on the back panel and through internal USB headers. The motherboard uses ASUS’s exclusive software like Armoury Crate, Fan Xpert 2+, Power Saving, Two-Way AI Noise Cancellation, AI Suite 3, DIGI+ VRM, PC Cleaner, ASUS CPU-Z, Norton 360 Deluxe (60 Days Free Trial), WinRAR.
| Processor | |
| Supported CPU |
Intel® Socket LGA1700 for 13th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0 |
| Mainboard | |
| Chipset |
Intel® B760 Chipset
|
| BIOS |
128 Mb Flash ROM, UEFI AMI
|
| Memory | |
| Memory |
2 x DIMM slots, Max. 96GB, DDR5
8000(OC)/7800(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) |
| Storage | |
| Supported Storage |
Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
Intel® 13th & 12th Gen Processors: - M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) Intel® B760 Chipset: - M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) - 4 x SATA 6Gb/s ports |
| Graphics | |
| Graphics |
1 x VGA port
1 x HDMITM port |
| Audio & Microphone | |
| Audio |
Realtek 7.1 Surround Sound High Definition Audio CODEC:
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback Audio Features: - Audio Shielding - Premium audio capacitors - Dedicated audio PCB layers |
| Ports | |
| Slots |
Intel® 13th & 12th Gen Processors: 1 x PCIe 4.0 x16 slot
Intel® B760 Chipset: 2 x PCIe 4.0 x1 slots |
| Internal I/O Ports |
Fan and Cooling related:
- 1 x 4-pin CPU Fan header - 2 x 4-pin Chassis Fan headers Power related: - 1 x 24-pin Main Power connector - 1 x 8-pin +12V Power connector Storage related: - 2 x M.2 slots (Key M) - 4 x SATA 6Gb/s ports USB: - 1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports - 2 x USB 2.0 headers support 3 additional USB 2.0 ports Miscellaneous: - 2 x Addressable Gen 2 headers - 1 x Aura RGB header - 1 x Clear CMOS header - 1 x COM Port header - 1 x Front Panel Audio header (AAFP) - 1 x S/PDIF Out header - 1 x Speaker header - 1 x SPI TPM header (14-1pin) - 1 x 10-1 pin System Panel header |
| USB |
Rear USB (Total 6 ports)
- 4 x USB 3.2 Gen 1 (5G) ports (4 x Type-A) - 2 x USB 2.0 ports (2 x Type-A) Front USB (Total 5 ports) - 1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports - 2 x USB 2.0 headers support 3 additional USB 2.0 ports |
| Software | |
| Software Features |
Armoury Crate:
- Aura Sync - Fan Xpert 2+ - Power Saving - Two-Way AI Noise Cancellation AI Suite 3: - DIGI+ VRM - PC Cleaner ASUS CPU-Z: Norton 360 Deluxe (60 Days Free Trial) WinRAR ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode |
| Special Features | |
| Special Features |
ASUS 5X PROTECTION III:
- DIGI+ VRM - LANGuard - Overvoltage Protection - SafeSlot Core - Stainless-Steel Back I/O ASUS Q-Design: - Q-DIMM - Q-LED Core - Q-Slot ASUS EZ DIY: - ProCool ASUS Thermal Solution: - VRM heatsink design Aura Sync: - Aura RGB header - Addressable Gen 2 headers |
| Others | |
| Other Features |
Ethernet: 1 x Realtek 2.5Gb
Back Panel I/O Ports: - 4 x USB 3.2 Gen 1 (5G) ports (4 x Type-A) - 2 x USB 2.0 ports (2 x Type-A) - 1 x VGA port - 1 x HDMITM port - 1 x Realtek 2.5Gb Ethernet port - 3 x Audio jacks - 1 x PS/2 Keyboard/Mouse combo port Manageability: WOL by PME, PXE Cables: 2 x SATA 6Gb/s cables Operating System: Windows® 11, Windows® 10 64-bit |
| Physical Specification | |
| Form Factor |
mATX Form Factor
9.6 inch x 8.3 inch (24.4cm x 21.1cm) |
| Warranty Information | |
| Warranty |
3 Years
|
