GIGABYTE B760M D2H INTEL MOTHERBOARD PRICE IN BD
The GIGABYTE B760M D2H Intel Motherboard - the epitome of cutting-edge technology and performance for your computing needs. Designed to support 13th and 12th Gen Series Intel processors, this motherboard is a powerhouse of unparalleled performance and versatility. At the heart of this board lies the Intel® Socket LGA 1700, providing a stable and reliable platform for your high-end computing demands. The Hybrid 6+2+1 Phases Digital VRM Solution ensures optimal power delivery, guaranteeing smooth and stable operation even under heavy loads. Next-generation storage options abound, with two PCIe 4.0 x4 M.2 connectors for lightning-fast data access. The EZ-Latch feature on the PCIe 4.0x16 slot ensures easy and quick graphics card installation and removal. This micro ATX motherboard doesn't compromise on connectivity either. With HDMI and D-Sub ports, you can easily connect your display devices for immersive visuals. The GIGABYTE B760M D2H Intel Motherboard incorporates Smart Fan 6 technology with multiple temperature sensors and hybrid fan headers that intelligently regulate fan speeds for optimal cooling and quiet operation. In conclusion, the GIGABYTE B760M D2H Intel Motherboard combines top-notch performance, future-proof features, and user-friendly designs, making it an ideal choice for enthusiasts, gamers, and professionals alike. Upgrade your system today and experience a whole new level of computing excellence. Find the GIGABYTE B760M D2H Intel Motherboard at Techland BD and unlock the full potential of your PC.
| Mainboard | |
| Chipset |
Intel® B760 Express Chipset
|
| BIOS |
1 x 128 Mbit flash
Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Memory | |
| Memory |
Support for DDR5 8000(O.C.) /7800(O.C.) /7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules
2 x DDR5 DIMM sockets supporting up to 96 GB (48 GB single DIMM capacity) of system memory Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
| Graphics | |
| Graphics |
Integrated Graphics Processor-Intel® HD Graphics support
|
| Networking & Connectivity | |
| LAN |
Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
|
| Audio & Microphone | |
| Audio |
Realtek® Audio CODEC
High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out |
| Ports | |
| Slots |
CPU: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
Chipset: 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1 |
| Internal I/O Ports |
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB 3.2 Gen 1 header 3 x USB 2.0/1.1 headers 1 x Trusted Platform Module header 1 x serial port header 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper |
| USB |
Chipset:
6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header) Chipset+2 USB 2.0 Hubs: 4 x USB 2.0/1.1 ports available through the internal USB headers |
| Software | |
| Software Features |
Norton® Internet Security (OEM version)
LAN bandwidth management software |
| Physical Specification | |
| Form Factor |
Micro ATX Form Factor; 24.4cm x 22.5cm
|
| Warranty Information | |
| Warranty |
3 Years
|
