EnGenius ECW120 Wave 2 WiFi 5 Cloud Managed Indoor Wireless Access Point in Bangladesh

The EnGenius ECW120 is a Wave 2 Wi-Fi 5 Cloud-Managed Indoor Wireless Access Point designed to deliver fast, stable, and scalable wireless connectivity for small to medium-sized businesses, educational institutions, and enterprise environments. Engineered with a powerful Qualcomm® 717 MHz Quad-Core ARM Cortex-A7 processor, this access point supports high-performance networking with advanced features ideal for dense device environments. Operating concurrently on both 2.4 GHz and 5 GHz frequency bands, the ECW120 delivers a combined maximum data rate of up to 1,267 Mbps. The 2.4 GHz radio supports speeds up to 400 Mbps using 2x2 MIMO with VHT40 and 256-QAM, while the 5 GHz radio reaches up to 867 Mbps with VHT80 support. With MU-MIMO and Tx Beamforming (TxBF) technologies, the device ensures efficient data transmission and improved coverage, even in high-traffic environments. Each radio supports 2 spatial streams, enabling reliable connectivity for up to 128 concurrent users per band. The ECW120 is designed for ease of deployment and management with EnGenius Cloud integration. Administrators can remotely monitor, configure, and troubleshoot the access point via a centralized cloud dashboard, reducing the need for on-site IT resources. The device operates in both Access Point and Mesh modes, giving organizations the flexibility to expand or restructure their wireless network seamlessly. For power, the ECW120 uses 802.3af PoE or 12VDC input, offering flexibility in installation. It includes one Gigabit Ethernet port, one DC jack, and a reset button. Integrated 5 dBi omni-directional antennas ensure broad signal coverage indoors, while built-in features like Client Balancing and Auto Channel Selection optimize performance dynamically based on usage and interference. Though the ECW120 does not support BLE, DFS, AirGuard, or scanning radios, it remains a strong contender for those seeking reliable, high-performance wireless access in managed environments. Ideal for classrooms, offices, and retail spaces, the EnGenius ECW120 combines intelligent cloud management with advanced wireless capabilities to meet today’s connectivity demands efficiently and cost-effectively.

FAQs:

1. Does the ECW120 support mesh networking?

Yes, the ECW120 supports both Access Point and Mesh operation modes, allowing flexible wireless network expansion.

2. How many users can connect to the ECW120 simultaneously?

The ECW120 supports up to 128 concurrent users per radio, making it suitable for medium-density environments.

3. Can the ECW120 be powered using PoE?

Yes, it supports 802.3af Power-over-Ethernet, eliminating the need for a separate power adapter during installation.
