GIGABYTE B650M K AM5 AMD DDR5 MICRO-ATX MOTHERBOARD PRICE IN BD
The Gigabyte B650M K AM5 AMD DDR5 Micro-ATX Motherboard is a high-performance motherboard now available at TechLand BD. It is designed to support the latest AMD Ryzen 7000 Series Processors. It features the AMD B650 chipset and supports DDR5 memory modules with speeds up to 8000 MT/s. The motherboard has 4 DDR5 DIMM sockets, supporting up to 192 GB of system memory. The motherboard comes with an integrated graphics processor, supporting a maximum resolution of 3840x2160@144 Hz via DisplayPort and 4096x2160@60 Hz via HDMI. It also features a Realtek® Audio CODEC for high-definition audio and a Realtek® 2.5GbE LAN chip for fast network connectivity. The motherboard provides multiple expansion slots, including a PCI Express x16 slot and a PCI Express x1 slot. It also offers multiple storage interfaces, including two M.2 connectors and four SATA 6Gb/s connectors, with RAID support for both NVMe SSD and SATA storage devices. The motherboard also features multiple USB ports, including a USB Type-C® port with USB 3.2 Gen 2 support on the back panel and additional USB ports available through internal headers. The motherboard is equipped with an iTE® I/O Controller Chip and supports voltage detection, temperature detection, fan speed detection, and fan speed control. It uses a licensed AMI UEFI BIOS and supports GIGABYTE Control Center (GCC).
| Processor | |
| Supported CPU |
AMD Socket AM5, support for: AMD Ryzen™ 7000 Series Processors
|
| Mainboard | |
| Chipset |
AMD B650
|
| BIOS |
1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Memory | |
| Memory |
Support for DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800 MT/s memory modules
4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory Dual channel memory architecture Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules |
| Storage | |
| Supported Storage |
CPU:
- 1 x M.2 connector (Socket 3, M key, type 2580 PCIe 4.0 x4/x2 SSD support) - 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support) Chipset: - 4 x SATA 6Gb/s connectors RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
| Graphics | |
| Graphics |
1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz
1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz |
| Networking & Connectivity | |
| LAN |
Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
|
| Audio & Microphone | |
| Audio |
Realtek® Audio CODEC
High Definition Audio 2/4/5.1/7.1-channel |
| Ports | |
| Internal I/O Ports |
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) 1 x reset jumper 1 x Clear CMOS jumper |
| USB |
CPU:
- 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support - 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel - 2 x USB 2.0/1.1 ports on the back panel Chipset: - 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header - 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) - 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header) |
| Software | |
| Software Features |
Norton® Internet Security (OEM version)
LAN bandwidth management software |
| Special Features | |
| Special Features |
Support for GIGABYTE Control Center (GCC)
Support for Q-Flash Support for Q-Flash Plus |
| Others | |
| Other Features |
Expansion Slots:
- CPU: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 - Chipset: 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 Back Panel Connectors: - 1 x DisplayPort - 1 x HDMI port - 4 x USB 2.0/1.1 ports - 1 x PS/2 keyboard/mouse port - 1 x USB 3.2 Gen 2 Type-A port (red) - 1 x USB Type-C® port, with USB 3.2 Gen 2 support - 1 x Q-Flash Plus button - 1 x RJ-45 port - 2 x USB 3.2 Gen 1 ports - 3 x audio jacks I/O Controller: iTE® I/O Controller Chip - H/W Monitoring - Voltage detection - Temperature detection - Fan speed detection - Water cooling flow rate detection - Fan fail warning - Fan speed control Operating System - Support for Windows 11 64-bit - Support for Windows 10 64-bit |
| Physical Specification | |
| Form Factor |
Micro ATX Form Factor; 24.4cm x 24.4cm
|
| Warranty Information | |
| Warranty |
3 Years
|
-
