Name: V-SOL V1600D8 8 Port EPON OLT Network Switch
Brand: V-SOL
SKU: P4082506001
Price: 84000 BDT
Availability: InStock

V-SOL V1600D8 8 Port EPON OLT Network Switch

Stock : In Stock PID : P4082506001 SKU : TLV1600D8 Brand : V-SOL Model : V1600D8 Warranty : 1 Year

0 ratings

Discount Price

84,000৳ 87,000

Product Declaimer

EMI Start From*

৳ 2,958

View EMI Plans

V-SOL V1600D8 Specification

Management Mode	EMS, TR069 VACS, WEB, SNMP, Telnet , CLI
Operating Environment	Working Temperature 0°C ~ +50°C Storage Temperature -40 ~ +85°C Relative Humidity 5 ~ 90% (non-conditioning)
Power Consumption	45W
Power Supply	AC:100~240V, 47/63Hz, DC:-48V, BBU(option for D4-BT), Double Power Module Hot Backup
Weight (Single AC Power)	Net Weight: 4.5kg
PON Port Specification (PX20++ module)	Transmission Distance: 20KM EPON port speed Upstream: 1.25G, Downstream 1.25G Wavelength: TX 1490nm, RX 1310nm Connector: SC / UPC Fiber Type: 9/125μm SMF TX Power: +4.5 ~ +9dBm Rx Sensitivity ≤ -32dBm Saturation Optical Power: -8dBm
Management Ports	1FE out-band port, 1CONSOLE port
EPON Port	QTY: 8 Physical Interface: SFP Slots, PX20++ Connector Type, Max splitting ratio ≤ 1:64
GE/10GE Uplink Port	QTY: 16 RJ45(GE): 8 SFP(GE) : 4 SFP+(10GE): 4
Dimension (LWH)	442mm320mm43mm

V-SOL V1600D8 8 Port EPON OLT Network Switch in Bangladesh

EPON OLT Series

Pizza-box EPON OLT Meets Flexible and Fixed Broadband Deployment(4/8/16 Ports)

V-Solution, Better Solution

Compatible With All Brand EPON ONU

L3 OLT = L3 Router + L2 OLT

Provides Layer 3 dynamic routing protocols of RIP/OSPF, automatic routing switch for uplink to protect data transmission.

Easy Configuration, Plug & Play

Template configuration, plug and play, fast deployment

Powerful security protection

Firewall Based on flexible strategy can effectively resist all kinds of attacks.

Support BBU*

Stable working, non-stop power OLT
