MSI PRO B850-S WIFI6E AM5 ATX Motherboard in Bangladesh
MSI PRO B850-S WIFI6E AM5 ATX Motherboard, available at Tech Land BD, is a high-performance, business-oriented solution designed for AMD Ryzen 9000, 8000, and 7000 series processors, leveraging the AM5 socket and AMD B850 chipset for seamless compatibility with cutting-edge CPUs. This motherboard supports up to 256GB of DDR5 memory across four UDIMM slots, with overclocking speeds reaching an impressive 8200+ MT/s for Ryzen 9000 series, ensuring lightning-fast data transfer and enhanced system performance for gaming, content creation, and professional workloads. It features advanced connectivity with Wi-Fi 6E for ultra-low latency and high-bandwidth wireless networking, alongside a Realtek 2.5G LAN for stable, high-speed wired connections. The board includes two M.2 slots (one supporting PCIe 5.0 x4 for Ryzen 9000/7000 series) and four SATA 6G ports, with RAID 0, 1, and 10 support for flexible storage configurations. Its PCIe 5.0 x16 slot (for Ryzen 9000/7000) ensures compatibility with the latest GPUs, while the EZ PCIe Clip II simplifies graphics card installation. The motherboard also offers robust thermal management with M.2 Shield Frozr and 7W/mK MOSFET thermal pads, alongside Frozr AI Cooling for optimized fan performance. For multimedia, it provides HDMI 2.1 and DisplayPort 1.4, both supporting 4K at 60Hz, and Realtek ALC897 for 7.1-channel HD audio. With multiple USB ports (including USB 10Gbps Type-C), EZ Debug LEDs, and a user-friendly BIOS with features like AI Boost and Latency Killer, this motherboard delivers exceptional performance and ease of use. Purchase the MSI PRO B850-S WIFI6E from Tech Land BD to build a powerful, future-ready PC tailored for professionals and enthusiasts in Bangladesh.Does this motherboard support AMD Ryzen 7000 series CPUs?
Yes, the MSI PRO B850-S WIFI6E supports AMD Ryzen 7000 series processors with the AM5 socket.
What type of RAM does it support?
It supports DDR5 memory with speeds up to 6400+ MHz (OC) in dual-channel mode.
Does it have built-in Wi-Fi?
Yes, it features Wi-Fi 6E and Bluetooth 5.2 for wireless connectivity.
| Processor | |
| Supported CPU |
Ryzen 9000/ 8000/ 7000 |
| Chipset |
AMD B850 |
| Mainboard | |
| BIOS |
Flash BIOS Button |
| Memory | |
| Memory |
Type- DDR5 Slots- 4 x UDIMM Supported Memory Memory Support DDR5 8200 - 5600 Ryzen 9000 Series Processors max. 1DPC 1R Max speed up to 8200+ MT/s 1DPC 2R Max speed up to 6400+ MT/s 2DPC 1R Max speed up to 6400+ MT/s 2DPC 2R Max speed up to 6000+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only Maximum Memory- 256GB |
| Storage | |
| Raid |
Supports RAID 0, RAID 1, and Supports RAID 0 and |
| Supported Storage |
2x M.2 M.2_1 Source (From CPU) M.2_2 Source (From CPU) 4x SATA 6G M2_1 slot Supports up to PCIe 5.0 x4 Supports up to PCIe 4.0 x4 M2_2 slot Supports up to PCIe 4.0 x4 Supports up to PCIe 4.0 x2 |
| Graphics | |
| Graphics |
Graphics 1x HDMI Support HDMI 2.1, 1x DisplayPort Support DisplayPort 1.4, |
| Networking & Connectivity | |
| LAN |
Realtek 8125 2.5G LAN |
| WiFi |
Wi-Fi 6E The Wireless module is Supports MU-MIMO TX/RX, Supports 802.11 a/ b/ g/ n/ ac/ ax |
| Bluetooth |
Supports Bluetooth 5.3, FIPS, FISMA |
| Audio & Microphone | |
| Audio |
Realtek ALC897 7.1-Channel High Definition Audio 1x Front Audio (JAUD) |
| Ports | |
| Slots |
PCI 2x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E1 slot Supports PCIe 5.0 x16 Supports PCIe 4.0 x8 Supports PCIe 4.0 x4 M.2 Socket 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 22110/2280 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G M2_1 slot Supports up to PCIe 5.0 x4 Supports up to PCIe 4.0 x4 M2_2 slot Supports up to PCIe 4.0 x4 Supports up to PCIe 4.0 x2 |
| Internal I/O Ports |
1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 4x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports TPM (Trusted Platform Module ) 1x TPM pin header(Support TPM 2.0) |
| External I/O Ports |
Clear CMOS Button DisplayPort 2.5G LAN USB 10Gbps Type-A USB 5Gbps Type-A Wi-Fi / Bluetooth Audio Connectors Flash BIOS Button HDMI™ USB 10Gbps Type-A USB 10Gbps Type-C |
| USB |
4x USB 2.0 (Front) 4x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 3x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Rear) 1x USB 10Gbps Type C (Front) |
| HDMI |
1x HDMI 2.1 |
| Special Features | |
| Special Features |
4x EZ Debug LED 1x EZ Memory Detection LED |
| Physical Specification | |
| Form Factor |
ATX 243.84mmx304.8mm |
| Warranty Information | |
| Warranty |
3 years |
